Electromagnetic Lock (HZ-280BS)
THE HZ-280BS Series is a full-size 600 LBS Holding force Monitored Electromagnetic Lock for Double Leaf Doors are designed with the customer in mind to be robust, easy to install and secure.
All HZ-280BS Series Electromagnetic Lock are designed to provide voltage selectable options for 12VDC and 24VDC. The variety and flexibility of the HZ-280BS series electromagnetic lock are designed to lock your door electrically.
Product Description
Features
LED Visual Indication
Back- EMF Protection
Tamper Resistant Fixing
Magnetic Bond Sensor / Hall Sensor
Automatic Voltage Surge Protection Circuitry
Specification
| Holding Force | 600 LBS x 2 |
| Input Voltage | 12/24VDC field selectable |
| Current draw | 0.48A@ 12VDC x 2 ; 0.24A@ 24VDC x 2 |
| Dimensions | Lock Body 500×47×26mm or Armature plate 180×38×11mm |
| Weight | 8.81 LBS |
| Cycle Tested | 500,000 Cycles |
| Certification | CE, ROHS |
| UL Listed | UL294 Listed |
